INTRODUCTION TO QueSO by savage@apostols.org
===============================================================
When it comes down to computer-related information security audits,
having the right tools to detect active IPs, ports or OSes becomes
an important issue. On this last point (OS identification) is where
free software is clearly scarce, and the presently used methods are
brute-force based (to say the least):
rpcinfo
snmp
telnet
SendMail version
download binaries from the public-ftp (analyzing its format)
and another slow and suspicious stuff..
Seeing the problem, I started writing a program a year ago (Abr.97)
with the ability of differentiating between a Linux and a Windows box
sending TCP packets to a listen port. A full featured TCP connection
is never really established, so it's more of a fine-tuned thing than the
other methods previously exposed. On April '98 I re-took this theme, and
the result is QueSO (wos), which you can get at:
http://www.apostols.org/projectz/queso/
How we can determine the remote OS using simple tcp packets? Well,
it's easy, they're packets that don't make any sense, so the RFCs
don't clearly state what to answer in these kind of situations.
Facing this ambiguous, each TCP/IP stack takes a different approach
to the problem, and this way, we get a different response. In some
cases (like Linux, to name one) some programming mistakes make the OS
detectable.
What packets does QueSO send?
0 SYN * THIS IS VALID, used to verify LISTEN
1 SYN+ACK
2 FIN
3 FIN+ACK
4 SYN+FIN
5 PSH
6 SYN+XXX+YYY * XXX & YYY are unused TCP flags
All packets have a random seq_num and a 0x0 ack_num.
On response to to packet 0 (SYN), any LISTEN port must answer a
SYN+ACK with a nonzero ack_num, seq_num and window, or, in case
of not being LISTEN, it'll send back a RST+ACK with the valid
ack_num. Here finishes the standard, and we get into QueSO-terrain :)
As it would be way too long to explain every test done and its results,
I think the best will be to explain QueSO's configuration file format.
The file queso.conf is formed by blocks of lines, delimited by the name
of the OS (starting with a *) and a trailing (white-spaced) line:
Start> * Linux 1.x, 2.0 (by savage@Apostols.Org)
0 1 1 1 SA
1 0 0 0 R
2 - - - - /* pkt#2 == Doesn't give any answer whatsoever */
3 0 0 0 R
4 1 1 1 SFA /* pkt#4 == seqnum, acknum, window, SYN+FIN+ACK */
5 - - - -
6 1 1 1 SAXY
End>
* blah, blah ...
As I've stated previously, it sends 7 packets (0-6), and compares
the responses with the config file, where the different OSes are
described, in a response-based way to each packet (differentiated
by the dst port -my port).
- First column is, thus, the pakcet number.
- Second one is seq_num ( 1/0/- )
- Third, ack_num ( 1/0/- )
- The Fourth is the window ( 1/0/-/hex_value )
- Fifth is flags ( S=SYN, F=FIN, R=RST, A=ACK, P=PSH, U=URG, X, Y )
i.e. a Linux:
2 - - - - -=> pkt#2 == No response
4 1 1 1 SFA -=> pkt#4 == seqnum, acknum, window, SYN+FIN+ACK
If in a block we don't include any of the 7 packets, it means we don't care
at all about its contents to pin down what OS we're dealing with.
Implementation:
---------------
If we run queso w/o args, it shows off "usage()"
[root@apostols queso]# ./queso
QueSO (c) 1998 savage@apostols.org
Usage: queso [-v] [-d] [-w] [-f srcIP] [-c file] [-t seconds] host.com[:port]
-v Version
-d Debug mode, print received PKTs.
-w Update queso.conf when new OS is found.
-f srcIP Select correct In/Out IP.
-c file Alternate config file.
-t seconds Set reception timeout. (default=3)
-n times How many times PKTs are sent. (default=1)
I think its self-explaining..
Salut, < savage@apostols.org >
---- 8< ----------------------------------------------------------
CVS: $Id: Documentation.txt,v 1.3 1998/09/15 21:34:37 savage Exp $
---------------------------------------------------------- >8 ----
|
| ![]() |
