Written by [yAtEs] ------ REaP --- Reverse Engineering aND Programming --- Http://reap.tsx.org / to contact me email, Jamesluton@hotmail.com



NEEDED:



SoftICE

Hex ED

Pen and Paper :)



Heya welcome to another one of my great CD tuts :), i'm gonna

explain howto rip C&C2, this one i found a bit tricky certainly

the hardess i've done, and that doesn't include Cdilla :P, anyways

lets get on.



This check had me stuck for a day or so and i had to sleep on it

i ended up doing a instruction compare, and learning a new lesson

on approachs to cd checks.



Right lets get on and crack this baby, first of all take CD 1 and

install, notice theres no installation type. Once the game has installed

your notice that you have only 32mb installed on your computer, this

can't be right we will need some more file(s) from the CD, anyway

remove your CD and store safely, now run the game, what do we see?



We see a error msg box which doesn't want to screen grab, n/m i'm

sure you know what it looks like, now we have a Ok button and if we

click it nothing happens apart from maybe a small screen refresh, this

is good because we know that its checking something when we click

OK, we'll just find out what its doing by setting our breakpoints now.



Sooo what could it be doing? well our best bet is than its searching

for a file, so lets check that by typing in SoftICE,

BPX CreateFileA DO "D esp->4"

you might think WTF does that do? well its break with a extra function

you may already know what it means but for you unprivenged people

i'll explain, this means break when the api CreateFileA is called,

SoftICE will popup and DO a "D esp->4" thats dump 4th item on the

stack pointer(ESP), well i think it means that :P



Right now we are setup, click OK and see what happens, so what did

happen? Well when i did it nothing, so i spent a few hours trying

every single stupid API i could think of, but no joy, so then

guess what, i figured out you needed a CD in the drive duh..

hehe anyways back to the msg box, now make sure you have any old CD

in the drive apart from the Red Alert ones :P, now make sure you have

the breakpoint set, click OK, what happens, yay! a break.

eEk! lotz of text............................

:) ok so the program breaks what do you notice?, yes! in our

dump window it says 'E:\main.mix' press F5 and bang it breaks again

looking for the same file, then we are returned to the msg box, hmmm

well we have a new mission :) to make the program read Main.mix

from somewhere else, so lets start by copying it to our harddrive,

i copied mine to C:\ the root directory would be best.



Ok we now have the task of making it read of the C drive, cos i;m dumb

and not very good at this CD check lark ;)) it took me a while to figure

out it was GetDriveTypeA that finds the Cdrom Drive letter and stores it

for later use, so all we have to do it make this API return the Harddisc

as a CDROM, if you don't understand to Getdrivetype API i recommend you

look it up in the Win32Api ref, you'll find it pushes a drive letter

and when the api is called it will return its type, so for e.g it would

push A:\ and return 2 in EAX as 2 means Removable Drive, 3 means Fixed

and 5 means CDROM thats all we need know.



So now exit to windows and set this break point BPX GetDriveTypeA DO "D esp"

ok now click our RA95.exe icon cos thats what we are cracking by the way, hehe

and you'll see SoftICE will break and the dump window will say A:\ press F12

and you'll see this code :-



015F:005B5090 89E0 ....................................MOV EAX,ESP

015F:005B5092 50 ........................................PUSH EAX <--- Push Drive Letter

015F:005B5093 885C2404 ...........................MOV [ESP+04],BL

015F:005B5097 2EFF1560026E00 ...............CALL CS:[KERNEL32!GetDriveTypeA] <- Call API

015F:005B509E 83F805 ...............................CMP EAX,05 <-- We are here

015F:005B50A1 75DD .................................JNZ 005B5080

015F:005B50A3 8B4668 ..............................MOV EAX,[ESI+68]



Ok what can we see from that code??? well look!! its comparing the

drive type to 5 a CDROM!, and A:\ isn't one so it jumps up, press F5

and SoftICE will jump again, this time it says B:\ and you should

get the general drift now, its comparing A:\ to Z:\ to see which

is a CDROM Drive, this is done at the CMP EAX,05 Soooooo lets change

this to CMP EAX,03, i tried pressing A and typing in CMP eax,03 but it

just messed up because of the length of the instruction or some Sh*t,

anyway we will have to change the HEX code, if you look it says 83F805

hmm that means CMP EAX,05 so what ever could be CMP EAX,03 yes thats

right its 83F803 so at this point create a copy of RA95.exe and call it Crack.exe and search for '83F80375DD' notice the extra JNZ

code in there as well because there are several 83F805's in theres thats

just to make we have to right one, anyway patch that and save.



Now we have a exe which should in all theory run main.mix from C:\ ok now

save your work and run the EXE and lets see if the game works!

Ok so you just got back from rebooting your computer :P, or infact you

just skipped a few lines ahead and read this and thought WHAT!

hehehe, anyway if you ran it you would of noticed that the mouse pops

up then disappears as if the .MIX is loading, and i can you for a fact

it is, but i'm not allowed to tell you that because we don't know that

:P, aaaaaaaaaanyway so what the #"£! is wrong with it????, Hmmmm well

this is where i went to bed :P, next day i was like right.... tryed

lots of sh*t out, but couldn't see SoftICE due to C&C2's colour palette

which made SI invisable ,all black, so we have to resort to a instruction

cmp which old pen and paper, don't know if other crackers ever do this

but seems a bit lame :P, any i cracked it :D, right what we have to

do is go back to our orignal exe (RA95) and hoax the CreateFileA to

read in the .mix from the C drive and note down on paper all the jumps

and if they jump or not, then we do the same again but this time, we

insert the real CD before clicking OK, lets gooo ...



Ok clear ya breakpoints and double click RA95.exe when we get to

the error box goto into SoftICE and set the breakpoint BPX CreateFileA

now leave SoftICE and click OK when it breaks type E ESP now a new

window we open at the top of the screen and some where in there it will

say E:\main.mix with your mouse click the E and type C over it now press

enter, now press F12 to return to the code and you'll see that the

CreateFileA api has return 40 or 30 in EAX to say it read 40/30 bytes

instead of returning FFFFFFFF to say file not found, anyway from here on note

down all our jumps and if they jump all not, heres my list



004B67BF CMP EAX,-01

004B67C2 JZ ......... NO JUMP

004B67D6 JG ......... JUMP

004B6804 JNZ ........ JUMP

RET

004B693A Mov

004B693F JL ........ NO JUMP

004B6943 JZ ........ NO JUMP

004B6948 JZ ........ JUMP

004B6956 JNZ ...... JUMP

004B6ACD JLE ...... JUMP

004B6C52 JZ ....... JUMP



BLEH!! after that i though i'm not doing any more, i'm sure that was enough ;)

, ok now clear all breakpoints and back to the msg box, now insert your

C&C2 CD 1 first before setting the breakpoints !! go into SoftICE and

set BPX CreateFileA now leave SoftICE and click

Ok and when it breaks at CreateFileA once again press F12 to get back to the

code, and check all the exact same jumps for differences, heres my list.

004B67BF CMP EAX,-01

004B67C2 JZ ......... NO JUMP

004B67D6 JG ......... JUMP

004B6804 JNZ ........ NO JUMP

BANG!! there is our difference heres the code

015F:004B67FD E8AE910E00 ...........CALL 0059F9B0

015F:004B6802 85C0 ........................TEST EAX,EAX

015F:004B6804 75D7 ........................JNZ 004B67DD <--- BLEH!



If you trace on your notice that you get stuck in a mad loop, and thats why

when we ran our Crack.exe it jammed up, so what the hell!! lets NOP this jump

out!!, open up your Crack.exe and search for '85C075D7' ok now replace with

'85C09090' and Save now run our Crack.exe and they!!!!!!!!!! The Game works

~"£#£@$"£$ w00T!!! :) hehe, oh well, now that the game works, i went back

to investigate that Call 0059F9B0 to find out what it was about, and it was

just comparing C with A and some wired stuff, so i did a quick jump check

with the real CD and didn't find much out, until i have just finished writting

this doc.

I found out that the call was comparing C with S and i thought and thought

and remembered seeing a GetVolumeInformationA, so i looked up this and it

gets the Name of a drive, this happens to be E:\ in this case, and the

CD that i had in my drive was Shadow of the empire, the volume name was

'SHADOWS' then i reliased the first letter of this was S !!!, clever eh?

i quickly inserted a cd, that started with the letter R , guess what!!!

the Call compared R to C !!!!!!!!!!!!11 thats it i cryed!! its checking to

see if the first letter of the CD in the drive begins with a C , Jeezus!!

i'm sooooo dumb, anyway we managed to defeat that with some lame jump compares

and i thought i would write all this out just to show where people go wrong

how people think and blah blah blah :), if you just hex edit the getdrivetype

bit to cmp eax,03 and insert a CD beginning with the letter C you'll find it

works, but we have bypassed that anyway so thats it, a very long interesting

tutorial which will have no doubt taught me the lesson checking that programs

aren't checking the volume name, the API shall always be in the back of my

mind now :D, anyway must stop typing,



Laterz [yAtEs]
