How To Crack


Please do not cantact me if you have the Italian version of the game as it has Securom protection......Try using the latest veriosn of Procdump (v1.6) to dump the file the file than crack it. Although I have been to Italy many times and think it is a wonderful county, especially nothern Italy around Lago Di Garda and have have made many friends there, I really do not have time to answer all of the Italian queries that I have been getting about this..............This crack is for the UK VERSION only.........

First of all let me say that this tutorial is aimed at those beginner with a little knowledge of Soft-Ice/cracking. So if you've just bought the game and want to take it back after seeing how many bugs there are in it then this is for you! Or you can just goto the end of this tutorial to patch it with a Hex-Editor if you like

Download the official patch v1.1 from www.lucasarts.com patches page and apply it before going any further. It fixes few problems with the game. A main one is that the enemy actually try to dive for cover now rather than standing there like complete twats with targets on their foreheads shouting 'kill me, kill me !'.


OK then, what you need are the following tools to crack this game: Soft-Ice, Windows Dissasembler and a Hex-Editor.

Having got all of the tools then read on:

Do a maximum install of 870 MB, remove the CD from the drive and run the game setup/launcher. Start a new game or resume an old game and you will be told 'Please insert one of the product CDs into your CD-ROM drive to proceed.' You can't start a new game without the original CD in the drive.

With Soft-ice (SI) loaded do the following:

[1] There are a number of ways programs check for the existence of a CD in the CD-ROM drive. One is a call GetDriveTypeA and another is GetVolumeInformationA.

[2] Load the Jones3D.exe into the Windows Disassembler (WDASM) and goto the import functions and search for either of these references. The only one that exists is GetVolumeInformationA so run the launcher and then CTRL-D into Soft-Ice (SI) before selecting New Game or Resume Game.

[3] Set a breakpoint on the call, type 'bpx getvolumeinformationa' (without the quotes) then press enter. Now start a new game and you will be popped back into SI at the following location below. Try tracing each step and read the various registers as you go to see what information is being placed in them and read from them. Everything is commented below.
NOP refers to the instruction No OPeration which basically means do nothing/ignore.


------------------------------------------------------------------------------


* Reference To: KERNEL32.GetVolumeInformationA, Ord:0177h

:00403D67 FF1554C04000 Call dword ptr [0040C054] -----> We land here.

:00403D6D 85C0 test eax, eax -----------------------------------> If CD in drive then EAX=1. If not in drive EAX=0.
 :00403D6F 7473 je 00403DE4 ------------------------------------> Ignore the check by placing NOP NOP here.
:00403D71 8B4DEC mov ecx, dword ptr [ebp-14] -----------> J3D is placed in ECX, first 3 letters of the volume name on the CD.
:00403D74 3BCB cmp ecx, ebx ----------------------------------> Does the name match J3D on the CD?
:00403D76 7405 je 00403D7D -----------------------------------> Ignore the check by entering NOP NOP here.

:00403D78 8B41F0 mov eax, dword ptr [ecx-10]
:00403D7B EB02 jmp 00403D7F
* Referenced by a (U)nconditional or (C)onditional Jump at Address:
|:00403D76(C)
:00403D7D 33C0 xor eax, eax
* Referenced by a (U)nconditional or (C)onditional Jump at Address:
|:00403D7B(U)
:00403D7F 3BCB cmp ecx, ebx
:00403D81 889C05E0FEFFFF mov byte ptr [ebp+eax-00000120], bl
:00403D88 7405 je 00403D8F
:00403D8A 8B49FC mov ecx, dword ptr [ecx-04]
:00403D8D EB02 jmp 00403D91
* Referenced by a (U)nconditional or (C)onditional Jump at Address:
|:00403D88(C)
:00403D8F 8BCF mov ecx, edi
* Referenced by a (U)nconditional or (C)onditional Jump at Address:
|:00403D8D(U)
:00403D91 8D85E0FEFFFF lea eax, dword ptr [ebp+FFFFFEE0]

:00403D97 50 push eax -------------------------------------------> Name read from CD
:00403D98 51 push ecx -------------------------------------------> Name J3D on original
* Reference To: KERNEL32.lstrcmpiA, Ord:02FFh
:00403D99 FF15A8C04000 Call dword ptr [0040C0A8] -> Compare both names

:00403D9F 85C0 test eax, eax ---------------------------------> If matching then EAX=0, if not EAX= -1
:00403DA1 7541 jne 00403DE4 -------------------------------> Ignore the check by entering NOP NOP here.

This is as far as we need to go with the tracing as the launcher now calls the main file in the \resource folder to run the game so the game is now cracked in memory.

There are other ways of cracking the checks so this is by no means the only way to do it.

[4] Now quit the game and goto the locations mentioned in WDASM and write down the offset locations to the code we need to change to NOP NOP.


Load the Jones3D.exe into your Hex-Editor. The offsets are in hexadecimal as follows:

Offset 3D6F - change from 7473 to 9090
Offset 3D76 - change from 7405 to 9090
Offset 3DA1 - change from 7541 to 9090

OR...........try this simple way of cracking it without touching the exe file.

 Under the registry setting HKEY_Local_Machine\Software\LucasArts Entertainment Company LLC\Indiana Jones and the Infernal Machine\V 1.0\

Edit the value of the Key 'Source Dir' to 'C:\' then open the \install\setup.ini in the game folder and change the 'Data' value in the [Startup] section to the first 3 letters of the volume name of drive C:. eg if drive C: is called 'main' then change the value to 'mai' and that will crack the CD-check also.

i.e. Data = 'mai'



That's it then, the game is now cracked and ready to run..................hope you learned something.
