| Note: Lead count on this 3D picture may be different. This picture depicts the package type. |
|
JEDEC Spec: Plastic Metal LCC A
|
| Body Size | |||
|---|---|---|---|
| Wide Nom.: | 118.00 | mm | |
| Long Nom.: | 118.00 | mm | |
| Thickness: | 34.00 | mm | |
| Lead Frame | |||
| Material: | Copper | ||
| Lead Finish: | SN/PB | ||
| Pitch: | 19.7 | mm | |
| mub10a Mechanical Drawing (51 Kbytes) |  View Online |
 Download |
 Receive via Email |
 |
